405nm Blue Portable Laser (P7) |
|
|
Key Feature
|
Application
|
|
| BLM405P7 Series Laser | |||
| Parameter | |||
| Output Wavelength | 405±5nm | ||
| Output Power | 5~150mW | ||
| Spatial Mode | Near TEM00 | ||
| Operating Mode | CW | ||
| Beam Divergence, Full Angle | 0.5mrad | ||
| Beam Diameter @ 10m Distance | 6.0mm | ||
| Power Stability | 10% (RMS, over 2 hours, T= 25℃) | ||
| 20% (RMS, over operating temperature) | |||
| Switch | Push Button | ||
| Surface color | Black | ||
| Range in darkness | 1000~2000m | ||
| Power supply | 2 × CR2/3V Li Battery | ||
| Dimension | Ф23 × 194mm | ||
| Weight | 0.2Kg | ||
| Expected Operation Lifetime | 5000 hours | ||
| Warranty | 6 months | ||
| Laser Products | ||||
| Model | Output Power | Power Supply | Warranty | IEC/CDRH Laser Class |
| BLM405P7-001 | <1mW | 2 × CR2/3V Li Battery | 6 months | Class 2/II |
| BLM405P7-005 | <5mW | 2 × CR2/3V Li Battery | 6 months | Class 3R/IIIa |
| BLM405P7-010 | 10mW | 2 × CR2/3V Li Battery | 6 months | Class 3B/IIIb |
| BLM405P7-020 | 20mW | 2 × CR2/3V Li Battery | 6 months | Class 3B/IIIb |
| BLM405P7-030 | 30mW | 2 × CR2/3V Li Battery | 6 months | Class 3B/IIIb |
| BLM405P7-050 | 50mW | 2 × CR2/3V Li Battery | 6 months | Class 3B/IIIb |
| BLM405P7-100 | 100mW | 2 × CR2/3V Li Battery | 6 months | Class 3B/IIIb |
| BLM405P7-150 | 150mW | 2 × CR2/3V Li Battery | 6 months | Class 3B/IIIb |
| Mechanical Drawing | ||
 |
